Drawing for Engineering – For multi-disciplinary draughting

Product Details:
Author(s):
Meyer, W
Year Published:
2025
Edition
1st Edition
Type:
Print | Soft Cover
Language:
English
About this publication
Drawing for engineering is focused on introducing drawing principles for multi-disciplinary draughting from a foundational level to a tertiary level, it focuses on the technical aspects of creating industry-standard engineering drawings in compliance with the South African Bureau of Standards Code Practice for Engineering Drawing SABS 0111.  It is a step-by-step guide to draughting professional engineering drawings and drawing techniques.
Content
Unit 1: Drawing Equipment
Unit 2: Applications on the alphabet of lines
Unit 3: Lettering, Figuring and Dimensioning
Unit 4: Free hand sketching
Unit 5: Construction
Unit 6: Layout and drawings
Unit 7: Sectioning
Unit 8:  Conventional representation
Unit 9: Fasteners
Unit 10: Assembly drawings
Unit 11: Pipe drawings
Interest / Benefit to
2nd year students
